In December 2020 I provided online Wireshark training to one of our NVISO clients. During the second day, when we cover the development of custom dissectors written in Lua, a question about CSV data came up. When the data exchanged over TCP, for example, has the CSV format (fields separated by a separator), how can I write a dissector for that?

While answering the question, I realized that this is a case that could be solved with a generic dissector. And the same night, I developed the first version.

Say you have a packet capture with a TCP connection. And the data exchanged over TCP consists of different fields, separated by a separator character.

Like this example:

Because Wireshark does not recognize the protocol used in this TCP connection, the content is just displayed as data.

With Lua dissector csv-dissector.lua, the data is dissected into different fields:

The separator character (pipe character | in this example) is something that can be configured:

Other changes can be made, but these have to be made in the code of the dissector itself:

• Changing the port
• Changing the number of fields
• Change the name of the fields

Download:

csv_dissector_V0_0_2.zip (https)

MD5: E8CCE089FB0574775AB39DADED3B7AA2

SHA256: 5C8DC0F2BB97AA660E2576B23379B6F12FB88126F0EFC7A2F69E76EBA8E782BD

This is a topic I’m teaching in my “Packet Class: Wireshark” training in Amsterdam next month.

You can configure Wireshark to display TCP flags like Snort does. One way to do this, is to create a post-dissector and then add a column with its output (like in the screenshot above).

I developed a Wireshark Lua dissector generator. You provide it some definitions, like this:

[dissector]
file_prefix = tcp-flags
type = postdissector
description = Wireshark Lua tcp-flags postdissector example

[protocol]
proto = tcpflags
description = TCP Flags Postdissector

[protocolfields]
field_1 = flags
description_a_1 = TCP Flags
description_b_1 = The TCP Flags

[fields]
field_1 = tcp.flags

And then my Python program lua-dissector-generator.py takes this input and generates a Lua post-dissector with one new protocol + field, using an existing field.

--[[
	2014/02/21 - 2014/02/21
	tcp-flags-postdissector.lua V0.0.1
	Wireshark Lua tcp-flags postdissector example

	Source code by Didier Stevens, GPL according to Wireshark Foundation ToS
	https://DidierStevens.com
	Use at your own risk

	Shortcommings, or todo's 😉

	History:
		2014/02/21: start
--]]

local function DefineAndRegister_tcpflags_postdissector()
	local oProto_tcpflags = Proto('tcpflags', 'TCP Flags Postdissector')

	local oProtoFieldflags = ProtoField.string('tcpflags.flags', 'TCP Flags', 'The TCP Flags')

	oProto_tcpflags.fields = {oProtoFieldflags}

	local oField_tcp_flags = Field.new('tcp.flags')

	function oProto_tcpflags.dissector(buffer, pinfo, tree)
		local tcp_flags = oField_tcp_flags()

		if tcp_flags ~= nil then
			local oSubtree = tree:add(oProto_tcpflags, 'TCP Flags')
			oSubtree:add(oProtoFieldflags, tcp_flags.value)
		end
	end

	register_postdissector(oProto_tcpflags)
end

local function Main()
	DefineAndRegister_tcpflags_postdissector()
end

Main()

Finally, we add functions to represent the individual TCP flags:

local function DecodeFlag(flags, mask, character)
	if bit.band(flags, mask) == 0 then
		return '*'
	else
		return character
	end
end

local function TCPFlagIntegerToSnort(tcpflags)
	local s_tcp_flags = ''

	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x80, 'C')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x40, 'E')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x20, 'U')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x10, 'A')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x08, 'P')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x04, 'R')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x02, 'S')
	s_tcp_flags = s_tcp_flags .. DecodeFlag(tcpflags, 0x01, 'F')

	return s_tcp_flags
end

That’s it. You can download this post-dissector here:

wireshark-lua-dissectors_V0_0_3.zip (https)
MD5: 73F9BB860F2204DBDE7FF3A7E5CA413F
SHA256: 900A21C862973294AB25A8966299386BD058A352CEA21CA97BA546DA12964465
